H-Series
Classification： Chip Varistor
Product introduction：This series of pressure-sensitive zinc oxide semiconductor package, compact size, SMD type for high-density installation, bi-directional symmetrical non-linear V-I voltage limiting curve, excellent voltage limiting ratio and fast response time (<10ns), high impact resistance and power stability,
Product details
This series of pressure-sensitive zinc oxide semiconductor package, compact size, SMD type for high-density installation, bi-directional symmetrical non-linear V-I voltage limiting curve, excellent voltage limiting ratio and fast response time (<10ns), high impact resistance and power stability, excellent solderability (Ni, Sn coating). Package size 0402, 0603, 0805, 1206, 1210, 1812, 2220 several, more in the DC-DC side of the power line to absorb lightning induced overvoltage and absorption of the line's own surge energy, generally used for secondary protection.
